KC-12001B

Electro Acoustic Specification

Nominal Chassis Diameter      12"
Nominal Impedance                8Ω
Power Handing                      300W A.E.S.
Peak Power                          1200W A.E.S.
Sensitivity(1w/1m)                  97dB
Usable Frequency Range        56Hz - 20KHz
Voice Coil Diameter                LF: 2.5"/63.5mm HF: 1.75"/ 44mm
Voice Coil DC Resistance       LF: 5.2 Ω  HF 5.5 Ω
Flux Density                          LF:1.3 Tesla / HF 1.8 Tesla


Material of Construction

Coil Former                            Glass Fiber
Voice Coil Material                  CCAW
Chassis                                  Die Cast Aluminium
Magnet Material                       Ferrite


Mounting /Shipping Information

Overall Diameter                     12.24"/311 mm
Depth                                     194.5 mm
Weight                                    7.6 kg
Shipping Weight                      8.2 kg
Packing Carton Dimensions     33*33*23cm
Bolt Fixing Hole Dim and Qty   8*∮6.5mm on 295mm PCD
