KC-6001

Electro Acoustic Specification

Nominal Chassis Diameter       6"
Nominal Impedance                 8Ω
Power Handing                       125W A.E.S.
Peak Power                            500W A.E.S.
Sensitivity(1w/1m)                   93dB
Usable Frequency Range         65Hz - 20KHz
Voice Coil Diameter                 LF:2.0"/50mm; HF:1.35/34.4mm
Voice Coil DC Resistance        LF:5.2 Ω/ HF:7.2 Ω
Flux Density                           LF:1.1 Tesla; HF:1.6 Tesla


Material of Construction

Coil Former                             Glass Fiber
Voice Coil Material                   CCAW
Chassis                                  Die Cast Aluminium
Magnet Material                       Ferrite


Mounting /Shipping Information

Overall Diameter                      6.57"/166.8mm
Depth                                     132 mm
Weight                                    3.2 kg
Shipping Weight                      3.8 kg
Packing Carton Dimensions     19*19*18cm
Bolt Fixing Hole Dim and Qty   4*∮4.5mm on158mm PCD
