KC-8001

Electro Acoustic Specification

Nominal Chassis Diameter     8"
Nominal Impedance               8Ω
Power Handing                      225W A.E.S.
Peak Power                          900W A.E.S.
Sensitivity(1w/1m)                 96dB
Usable Frequency Range       60Hz - 20KHz
Voice Coil Diameter               LF:2.5"/63.5mm; HF:1.75/44mm
Voice Coil DC Resistance      5.2 Ω
Flux Density                         LF:1.2 Tesla; HF:1.6 Tesla


Material of Construction

Coil Former                             Glass Fiber
Voice Coil Material                  CCAW
Chassis                                  Die Cast Aluminium
Magnet Material                       Ferrite


Mounting /Shipping Information

Overall Diameter                     8.27"/210mm
Depth                                    150 mm
Weight                                   5.6 kg
Shipping Weight                     6.0 kg
Packing Carton Dimensions     24*24*18cm 395X220X175 2pcs/ ctn
Bolt Fixing Hole Dim and Qty   4*∮5.5mm on 197mm PCD
