KT-6002

Electro Acoustic Specification

Sound Channel / Throat Size   1" /25.4mm
Nominal Impedance                8Ω
Power Handing                      40W A.E.S.
Sensitivity(1w/1m)                  113dB
Usable Frequency Range        1.0KHz - 20KHz
Recommended Crossover        above 2kHz
Frequency Filtered at
18dB /Octave
Voice Coil Diameter                 1.75"/44.4mm
Voice Coil DC Resistance        6.3 Ω
Flux Density                           1.85 Tesla


Material of Construction

Coil Former                              Kapton
Voice Coil Material                   Copper Clad Aluminium
Diaphragm material                  Polyester
Magnet Material                       Ferrite


Mounting /Shipping Information

Overall Diameter                       4.3" /110mm
Depth                                      1.85" /47mm
Weight                                    1.53 kg
Shipping Weight                       1.7 kg
Packing Carton Dimensions      12*12*6cm
Bolt Fixing Hole Dim and Qty   Screw Fit  2xM6 holes on Φ76.2
