KT-6005

Electro Acoustic Specification

Sound Channel / Throat Size    1" /25.4mm
Nominal Impedance                8Ω
Power Handing                       30W A.E.S.
Sensitivity(1w/1m)                   106dB
Usable Frequency Range        2KHz - 18KHz
Recommended crossover        above 2kHz
Frequency Filtered at
18dB /Octave
Voice Coil Diameter                1.4"/36mm
Voice Coil DC Resistance        6.3 Ω
Flux Density                           1.45Tesla


Material of Construction

Coil Former                              Kapton
Voice Coil Material                   Aluminium
Diaphragm material                  Polyester
Magnet Material                       Ferrite


Mounting /Shipping Information

Overall Diameter                     3.5" /90mm
Depth                                     2" /49mm
Weight                                   1 kg
Shipping Weight                      1.1kg
Packing Carton Dimensions    11*11*6cm
Bolt Fixing Hole Dim and Qty   Screw Fit  2xM5 holes on Φ76
