KT-6008

Electro Acoustic Specification

Sound Channel / Throat Size    1" /25.4mm
Nominal Impedance                8Ω
Power Handing                       40W A.E.S.
Sensitivity(1w/1m)                   110dB
Usable Frequency Range        1KHz - 20KHz
Recommended crossover        above 2kHz
Frequency Filtered at
18dB /Octave
Voice Coil Diameter                1.75"/44.4mm
Voice Coil DC Resistance        6.3 Ω
Flux Density                           2.20Tesla


Material of Construction

Coil Former                              Kapton
Voice Coil Material                   Copper Clad Aluminium
Diaphragm material                  Polyester
Magnet Material                       Neodymium


Mounting /Shipping Information

Overall Diameter                     3.35" /85mm
Depth                                     2.09" /53mm
Weight                                   0.86 kg
Shipping Weight                      1.0kg
Packing Carton Dimensions    10*10*7cm
Bolt Fixing Hole Dim and Qty   1-3/8”  18N screw
