KT-6010

Electro Acoustic Specification

Sound Channel / Throat Size    1" /25.4mm
Nominal Impedance                8Ω
Power Handing                       40W A.E.S.
Sensitivity(1w/1m)                   106dB
Usable Frequency Range        1.5KHz - 18KHz
Recommended crossover        above 2kHz
Frequency Filtered at
18dB /Octave
Voice Coil Diameter                1.75"/44.4mm
Voice Coil DC Resistance        5.3 Ω
Flux Density                           1.6Tesla


Material of Construction

Coil Former                             Kapton
Voice Coil Material                   Aluminium
Diaphragm material                  Polyester
Magnet Material                       Ferrite


Mounting /Shipping Information

Overall Diameter                      4.13" /105mm
Depth                                     2.48" /63mm
Weight                                   1.65 kg
Shipping Weight                      1.9kg
Packing Carton Dimensions     11.5*11.5*7cm
Bolt Fixing Hole Dim and Qty   Screw Fit  4xM5 holes onΦ76.2
