KT-6011

Electro Acoustic Specification

Sound Channel / Throat Size    1" /25.4mm
Nominal Impedance                8Ω
Power Handing                       40W A.E.S.
Sensitivity(1w/1m)                   110dB
Usable Frequency Range        1.2KHz - 20KHz
Recommended crossover        above 2kHz
Frequency Filtered at
18dB /Octave
Voice Coil Diameter                1.75"/44.4mm
Voice Coil DC Resistance        6.3 Ω
Flux Density                           1.78Tesla


Material of Construction

Coil Former                              Kapton
Voice Coil Material                   Copper Clad Aluminium
Diaphragm material                  Titanium
Magnet Material                       Ferrite


Mounting /Shipping Information

Overall Diameter                     4.45" /113mm
Depth                                     2.28" /58mm
Weight                                   1.65 kg
Shipping Weight                      1.75kg
Packing Carton Dimensions     12*12*7cm
Bolt Fixing Hole Dim and Qty   Screw Fit  2xM6 holes onΦ76.2
