KT-6015

Electro Acoustic Specification

Sound Channel / Throat Size  1.4" /36mm
Nominal Impedance                8Ω
Power Handing                       100W A.E.S.
Sensitivity(1w/1m)                   110dB
Usable Frequency Range        1.0KHz - 18KHz
Recommended crossover        above 1.5kHz
Frequency Filtered at
18dB /Octave
Voice Coil Diameter                3"/75mm
Voice Coil DC Resistance       5.6 Ω
Flux Density                            1.85 Tesla


Material of Construction

Coil Former                              Kapton
Voice Coil Material                   Aluminium
Diaphragm material                 Titanium
Magnet Material                       Neodymium


Mounting /Shipping Information

Overall Diameter                     4.89" /124mm
Depth                                      2.36" /60mm
Weight                                     2.15 kg
Shipping Weight                      2.38 kg
Packing Carton Dimensions    13.5*13.5*7cm
Bolt Fixing Hole Dim and Qty   Screw Fit  4xM6 holes on Φ101.6
