KW-1004N

Electro Acoustic Specification

Nominal Chassis Diameter     10"
Nominal Impedance                8Ω
Power Handing                      300W A.E.S
Peak Power                          1200W A.E.S
Sensitivity(1w/1m)                  97dB
Usable Frequency Range        55Hz - 5KHz
Voice Coil Diameter                2.5"/63.5mm
Voice Coil DC Resistance       5.5 Ω
Flux Density                          1.3 Tesla


Material of Construction

Coil Former                            Glass Fiber
Voice Coil Material                 Copper
Chassis                                 Die Cast Aluminium
Magnet Material                      Neodymium


Mounting /Shipping Information

Overall Diameter                     10.3"/262 mm
Depth                                    130 mm
Weight                                   2.75 kg
Shipping Weight                     3.3 kg
Packing Carton Dimensions     27.5*27.5*14.5 cm
Bolt Fixing Hole Dim and Qty   8*∮6.5mm on 246mm PCD
