KW-1005N

Electro Acoustic Specification

Nominal Chassis Diameter     10"
Nominal Impedance                8Ω
Power Handing                       300W A.E.S
Peak Power                            1200W A.E.S
Sensitivity(1w/1m)                   96.5dB
Usable Frequency Range       45Hz - 4.5KHz
Voice Coil Diameter                2.6"/65.5mm
Voice Coil DC Resistance       1.8 Ω
Flux Density                            1.4 Tesla


Material of Construction

Coil Former                              Glass Fiber
Voice Coil Material                   Copper
Chassis                                    Die Cast Aluminium
Magnet Material                       Neodymium


Mounting /Shipping Information

Overall Diameter                     10.4"/264 mm
Depth                                      115 mm
Weight                                     2.75 kg
Shipping Weight                      3.3 kg
Packing Carton Dimensions    27.5*27.5*13 cm
Bolt Fixing Hole Dim and Qty   4*∮6.5X9mm on 245mm PCD
