KW-15002

Electro Acoustic Specification

Nominal Chassis Diameter      15"
Nominal Impedance                8Ω
Power Handing                      600W A.E.S
Peak Power                          2400W A.E.S
Sensitivity(1w/1m)                  97dB
Usable Frequency Range       40Hz - 3.5KHz
Voice Coil Diameter               3"/76.9mm
Voice Coil DC Resistance      5.4 Ω
Flux Density                         1.1 Tesla

Material of Construction

Coil Former                              Glass Fiber
Voice Coil Material                   Copper
Chassis                                   Die Cast Aluminium
Magnet Material                        Ferrite


Mounting /Shipping Information

Overall Diameter                      15.5"/ 393 mm
Depth                                      166 mm
Weight                                     9.6 kg
Shipping Weight                       10kg
Packing Carton Dimensions       41.5*41.5*20 cm
Bolt Fixing Hole Dim and Qty     8*∮5.5X9mm on 374mm PCD
