KW-4001N

Electro Acoustic Specification

Nominal Chassis Diameter     4"
Nominal Impedance                8Ω
Power Handing                       30W A.E.S.
Peak Power                            120W A.E.S.
Sensitivity(1w/1m)                   91dB
Usable Frequency Range       100Hz - 13KHz
Voice Coil Diameter                1"/25.4mm
Voice Coil DC Resistance       5.6 Ω
Flux Density                            1.2 Tesla


Material of Construction

Coil Former                              Polyimide
Voice Coil Material                   CCAW
Chassis                                    Die Cast Aluminium
Magnet Material                       Neodymium


Mounting /Shipping Information

Overall Diameter                     4.25"/108 mm
Depth                                      62 mm
Weight                                     0.6 kg
Shipping Weight                      0.9 kg
Packing Carton Dimensions    12*12*8.5cm
Bolt Fixing Hole Dim and Qty   4*∮4.5mm on 115mm PCD
