KW-6001B

Electro Acoustic Specification

Nominal Chassis Diameter     6"
Nominal Impedance                2Ω
Power Handing                       90W A.E.S.
Peak Power                            360W A.E.S.
Sensitivity(1w/1m)                   94dB
Usable Frequency Range       65Hz - 6KHz
Voice Coil Diameter                1.5"/38.5mm
Voice Coil DC Resistance       1.6 Ω
Flux Density                            1.1 Tesla


Material of Construction

Coil Former                              Glass Fiber
Voice Coil Material                   CCAW
Chassis                                    Die Cast Aluminium
Magnet Material                       Ferrite


Mounting /Shipping Information

Overall Diameter                     6.89"/175 mm
Depth                                      86 mm
Weight                                     1.8 kg
Shipping Weight                      2.2 kg
Packing Carton Dimensions    18.5*18.5*10.5cm
Bolt Fixing Hole Dim and Qty   4*∮5.5mm on162mm PCD
